DLC-1500.8d AMPLIFIED LOUDSPEAKER CONTROLLER WITH DANTE & AES67

Name: Theory DLC-1500.8d - 8-CHANNEL LOUDSPEAKER CONTROLLER - WITH DANTE/AES67 — Theory Professional
Brand: Theory Professional
Availability: InStock

$0.00

The DLC-1500.8d delivers a massive 6000W in a 25 pound chassis. Capable of delivering 1500W into 4 or 8-ohms from any channel pair, or 800W into 2 or 4-ohms all channels driven, this 2U loudspeaker controller packs new levels of power into minimal rack space. If that weren’t enough, the DLC-1500.8d can drive 70V/100V hi-Z loudspeakers direct - no internal transformer required.

The DLC-1500.8d is equipped with 4-channels of Dante / AES67 audio-over-IP digital I/O making setting up and deploying even complex distributed audio systems painless and bullet-proof. No bulky analog audio cables are required (for 4 of the 8 channels). And, with new upgraded high-current output Euroblock connectors, the DLC-1500.8d can accept up to 10-gauge wire.

The DLC-1500.8d can drive up to 32 Theory 16-ohm loudspeakers in Lo-Z mode, or over 300 (!) in Hi-Z mode. You read that right, 300+ Theory speakers at 7.5W each.

The DLC loudspeaker controllers from Theory can be configured via its on-board web interface accessible via wired Ethernet, or via its on-board Wifi access point and includes matrix mixing, priority audio routing and ducking, parametric EQ, delay, gain and limiter DSP objects to make system optimization easy.

Full API and modules for AMX, Control4, Crestron, Crestron Home, ELAN, Josh.ai, Q-SYS, RTI, and Symetrix are available.

The DLC-1500.8d can drive up to 32 Theory 16-ohm loudspeakers in Lo-Z mode, or over 300 (!) in Hi-Z mode. You read that right, 300+ Theory speakers at 7.5W each.

Full API and modules for AMX, Control4, Crestron, Crestron Home, ELAN, Josh.ai, Q-SYS, RTI, and Symetrix are available.

GOTTA HAVE IT?

Click WHERE TO BUY above to find a Theory partner near you.

DLC-1500.8d SPECIFICATIONS


Description:	8-Channel Amplified Distribution Loudspeaker Controller with 4-Channels of Dante & AES67
	2U Chassis
	IP Control via Ethernet or Built-In WiFi Access Point
	LoZ BTL Mode
Operation:	LoZ and HiZ (70V/100V) Operation
Inputs:	8 x Balanced Analog Audio
	8 x RCA Unbalanced Analog Audio
	1 x S/PDIF Digital Audio
	4 x Dante / AES67 Digital Audio
Outputs:	8 x Speaker Outputs
	S/PDIF Digital Audio
	4 x Dante / AES67 Digital Audio
Trigger:	+12VDC
Audio Operation:	48kHz/24-bit
On-Board DSP:	48kHz/32-bit
DSP Features:	Loudspeaker Processing For All Theory Models
	Input Matrix Mixer
	5 Parametric Input EQ Filters
	Input Trim
	Stereo/Mono Inputs and Zones
	Signal Routing Including Priority Automatic Routing
	Audio Ducking
	10 Parametric Output EQ Filters
	Crossovers
	Gain
	Delay
	Polarity
	Peak and RMS Limiters
Frequency Response:	20Hz-20kHz, +/-0.25dB
Power Output:	4x 1500W (BTL) @ 100V
	4x 1200W (BTL) @ 70V
	8x 400W (SE) and 4x 1500W (BTL) @ 8-ohms
	8x 800W (SE) and 4x 1500W (BTL) @ 4-ohms
	8x 800W (SE) @ 2-ohms
Voltage Gain:	Variable
Input Sensitivity (selectable):	+14dBu
	+4dBu
	-10dBV (Unbalanced RCA)
	Microphone
Power Requirements:	Standby: <1W
	(1/8 power, all ch. driven): 470W
Idle Noise(A-Wt):	-78dBV
Signal to Noise Ratio:	>106dB
Distortion (1kHz, 1dB below max output):	<0.02%
AC Operation:	100V-240VAC, 50-60Hz
Terminals:	Euroblock Connector with Parallel Output
Outdoor Capability:	Indoor Use Only
Mounting Points:	Rack Mount Ears Included
Finish:	Matte Black
Dimensions:	3.50" H x 19" W x 12.6" D (89mm H x 483mm W x 320mm D)
Weight:	25.75 lbs. (11.68 kg)
Included Accessories:	Rack Ears

DLC USER INTERFACE

DLC-1500.8d ACCESSORIES

IT’S ALL ABOUT CONTROL.

The simple to install, set-up, configure, and customize DLC-CTRL provides PoE control of a Theory DLC amplifier zone right from the wall. Once connected, users can change the source or manage volume levels directly. Resembling modern lighting control, the sleek and discreet DLC-CTRL is available in a black or white premium finish. (North American version shown).
